Success stories from our clients
ECKOLD GmbH & Co. KG
The name ECKOLD stands for high-quality products and good service. As a pioneer of innovative clinching technology for joining sheets and profiles Eckold has an incomparable wealth of experience in the field of cold forming.
Product
- Clinch Machines
FEM analysis
- Static stress analysis
- Bolt Strengthening Instructions
- Strength analysis
Client feedback
- The conventional bolt calculation according to VDI2230 is usually very complex. In practice we have to consider many conditions which cannot be considered completely in the conventional calculation according to VDI2230 or make the calculation very complex and error-prone.
- Meshparts gives us the possibility to define larger assemblies with many screws and contact conditions as FEM models with a reasonable effort and to analyze several load cases comprehensively.
- Particularly successful is the fast definition or replacement of screws available in CAD with predefined FEM screws from the Meshparts library and the comprehensive static and dynamic screw evaluation.
- One of the highlights is the dynamic bolt evaluation under consideration of VDI2230, where the dynamic strength can be evaluated not only against the unloaded prestressing state, but also against any other load case.
Advantages
- We can design bolted connections with high safety.
- This saves unnecessary design loops and costs.
Bernd Polossek
ECKOLD GmbH & Co. KG
Construction - Design
